Waterbath

Description

Waterbath

Temperature
Setting temperature range +10 to +95 °C and boiling stage Working temperature range in °C
min. 5 above ambient up to +95 °C with additional boiling mode
Control of standard components
Temperature sensor 1 Pt100 sensor class A in 4-wire-circuit
Timer integrated digital timer from 1 min. to 99,59 hours for:ON continuous operationWAIT (delayed on for continuous andlimited timed operation)HOLD
Control technology
Controller digital display of set and actual temperature and of (remaining) programme time
Safety
Temperature control mechanical temperature limiter TB protectionclass 1 switching the heating off at approx. 30°Cabove max. temperature of the bath
Temperature control in case of overtemperature due to failure,the heating is switched off at approx. 10°Cabove the set temperature (fixed value)
Autodiagnostic system microprocessor PID-temperature controllerwith integrated autodiagnostic system withfault indicator
Heating concept
Heating Baths corrosion-proof large-area heating onthree sides Stainless steel interior
Dimensions
l(A) x w(B) x h(C): 350 x 290 x 140 mm
Interior easy-to-clean interior, made of stainlesssteel, reinforced by deep drawn ribbing,material no. 1.4301 (ASTM 304), laser-welded

Volume 14
Liquid level min. 97 mm Liquid level max. 120 mm
Textured stainless steel casing
Dimensions w(D) x h(G) x d(E): 578 x 347 x 436 mm Electrical data
Voltage 230 V, 50/60 Hz
Electrical load approx. 1800 W (during heating) Ambient conditions
Installation The vent openings in the left and back side must remain unobstructed. The distance to the wall must be at least 100 mm on the sides and at least 150 mm to the rear. The minimum spacing from the top
of the bath to the next ceiling is 750 mm. Ambient temperature +5 °C to +40 °C Humidity rh max. 80 %, non-condensing Overvoltage category II
Pollution degree 2
